Brand Name: SST LASER
Model: DL-D20
Material：ABS
Application：Hair removal
Language: English (Support Customized Language)
Suitable for:Beauty salon, hospitals, skin care centers,spa,etc …
OEM/ODM: Our factory can customize to meet your specific needs
Delivery Method: By Air, By DHL/TNT/FEDEX/UPS ,By Sea
Warranty: 2-Year Warranty
Diode laser 808 use special laser with long Pulse-Width 808nm,
can penetrate to hair follicle,laser can be preferentially absorbed by the melanin of the hair
and then heating the hair shaft and hair follicle,moreover to destroy the hair follicle.
Specification
| wavelength | 755nm 808nm 940nm 1064nm |
| Working
frequency |
1~10hz |
| Energy density | 1-100j/cm² /1-150j/cm2 |
| Cooling system | TEC auto+Water+Air+Refrigeration |
| Spot size | 12*26mm/14*39mm/12*30mm
optional |
| Output power | 500W/600W/800W/1000W/1200w/1600W/2400w |
| display | 15.6’ color touch screen |
| voltage | 220V/110Vavailable |
Application ：hair removal and skin rejuvernation
SST LASER 808nm Laser hair removal machine is the process of removing unwanted hair by means of exposure to pulses of laser light 808nm that destorys the hair follicle. The lasers damage the chromospheres by selectively heating them while leaving surrounding tissue unharmed. When treating unwanted hair, for example, the melanin in the hair folicles is targeted and damaged which results in the disruption of hair growth and regeneration. The diode laser is complemented by cooling technology and pain reducing methods which improve treatment efficacy and patient comfort.
755nm: Ideal for lighter skin tones and fine hair, offering strong melanin absorption for precise targeting.
808nm: The gold standard for most skin types and hair colors, delivering a balanced depth of penetration and power for efficient treatments.
940nm: Coagulates the microvessels around the hair follicle, cutting off the nutrient supply of hair follicles, sharply
reducing hair regeneration power, and completely inhibiting hair regeneration.
1064nm: Best suited for darker skin tones, offering the deepest penetration and safest treatment for medium to darker skin tones while minimizing risks of skin damage.
Cooling Temperature-25 ℃
Handpieces with 360°contact cooling. strong cooling, painless treatment. With strong TEC plate cooling technology, No pain during treatment, give patient a more comfortable treatment, and get a better treatment results.
American Laser Bars
Semiconductor laser and the laser palladium bars are imported from American, the energy is more stable
TEC Strong Cooling System
Better cooling system, can continuously work for 24 hours. Best thermostatic water cycle system guarantee semiconductor pump can’t burn cavities due to overheating.
Simple And Smart Menu
Auto alarm protection system of water flow, water level and water temperature on menu, Hidden failures can be early found and maintenance cost can be cut through the monitoring of machine status for you.
Changeable spotsize
12 x 18mm/12 x 24mm/12 x 30mm/12 x 30mm/5mm tapered tip
15.6-inch ultra-large 4K HD TFT touch color screen, lighter and thinner
Can choose male or female, body part, skin color.
4 wavelength for people with different skin colors
755nm 808nm 940nm 1064nm
| Laser Type | Diode Laser |
| Operation Interface | 15.6 inch Super Big Chromatic Touch Screen |
| 4 Laser Wavelength | 1064nm & 940nm & 808nm & 755nm |
| Energy | 10-150J/10-100J/cm² |
| Frequency | 1- 10Hz Continuous Adjustable |
| Laserhandlelifespan
Laser Handle Lifespan |
50,000,000 Shots |
| Spot Size | 12*36mm/12*30mm/12*24mm/12*18mm |
| Pulse Duration | 10-300ms Adjustable |
| Cooling System | TEC Semiconductorair+Water |
| Machine Power | 3500W |
| Electrical Source | 220V/50HZ or110V/60HZ |
| Crystal Temperature | -30℃ |
| Machine Temperature | 24°C Constant Temperature |
| Power Requirement | AC220V/110V 50~60Hz |
| Packing | 120 cmX50 cmX60 cm |
| Gross Weigh | 80KG |
